CFP4 LR4

CFP4 LR4

order
Hot pluggable CFP4 MSA form factor
Compliant to IEEE 802.3ba 100GBASE- LR4 and CFP-MSA-CFP4-HW-Specification
Up to 10km reach for G.652 SMF
Single +3.3V power supply
Operating case temperature: 0~70oC
Transmitter: cooled 4x25Gb/s LAN WDM EML TOSA (1295.56, 1300.05,1304.58, 1309.14nm)
Receiver: 4x25Gb/s PIN ROSA
4x28G Electrical Serial Interface (CEI- 28G-VSR)
MDIO management interface with digital diagnostic monitoring
Power consumption less than 6W
Duplex LC receptacle
RoHS-6 compliant
100GBASE-LR4 Ethernet
OTN OTU4
