Matrix Cable
10Gtek has developed a "matrix cable" to realize coordinated calculation of multiple groups of computing units and to distribute computing power faster in supercomputing. The matrix cable can realize any interconnection of 8 groups of QSFP28 (32 x 25G ports).
Immersion Cooling System
10Gtek QSFP28 Extender is designed to be applied for immersion solution. It extends the 100G interfaces to surface, aiming to realize the interconnection of 100G transceivers and AOC cables.
QSFP+ Extender
10Gtek's QSFP+Extender is used for long-distance transmission of QSFP+. The QSFP+Port could be transferred/converted into 4x SFP+port by Direct Attach Copper (DAC) technology under very lower insert lose. 10Gtek's QSFP+Extender are provided in 1U rack and movable version with 3.3V power supply. Transmission distance could be extended longer by connecting with Stable SFP+Transceivers.
QSFP28 Extender
100G Solution for Liquid Immersion Cooling System Liquid cooling has been an accepted method of conditioning electronics for more than half a century. Immersion Cooling is at the foundation of Immersed Computing. It means the complete immersion of electronic components in a dielectric liquid. By doing so, all the heat generated by the IT is captured in the liquid. Suitable dielecric liquids can absorb approximately 1500 times more heat energy than air with the same volumes and temperatures.
Transceivers
SFP+ transceiver is a standardized form factor for fiber optic and is used in datacom and telecom optical links, offering a smaller footprint and lower power consumption than XFP transceivers. Initial standard applications focused on 8G & 10G Fiber Channel, 10G Ethernet, SONET OC-192, SDH STM-64.
DAC(Direct Attach Cable)
DACs are widely chosen by data centers for connecting servers to the Top Of the Rack(TOR) switch as they are passive, consume zero power, have the lowest latency and cost-effective. DAC is the ideal option for data centers, super computers and other circumstances similar. 10Gtek offers a wide range of products for 0.5m to 10m lengths and in QSFP+, SFP+, XFP, CX4 form factors.
100G QSFP28 DAC
10Gtek’s QSFP28 passive copper cable assemblies feature eight differential copper pairs, providing four data transmission channels at speeds up to 28 Gbps per lane, and meet 100G Ethernet and Infiniband Enhanced Data Rate (EDR) requirements. Offered in a broad range of wire gages (from 30AWG through 26AWG), this 100G copper cable assembly features low insertion loss and low cross talk. QSFP28 form factors can be used with current 40G and 100G applications with substantial signal integrity margin.
100G QSFP28 AOC
10Gtek’s active optical cable assemblies use state-of-the-art technology to provide cost effective high data throughput interconnects. The cables incorporate E/O and O/E conversion built into the connector shell to yield a dramatic improvement in PCB real estate utilization. Using 850 nm VCSEL technology, the active cable assemblies will operate over a data rate of 25 Gb/s per lane with an aggregate data rate of 100 Gb/s in each direction.
AOC(Active Optical Cable)
10Gtek's SFP+ Active Optical Cables are hot-swappable, low-voltage cable assemblies that connect directly into SFP+ modules at both ends. These cables use a 20-position connector with active circuitry to increase distances and to improve EMI and reduce signal loss. 10Gtek's SFP+ Active Optical cable transmits 10Gbps data in each direction over a loose tube fiber with distance up to 100m.
Automatic Assembly Line (DAC Cable )
10Gtek’s automatic assembly line, assures the consistency of manufacture under the process of laser cutting, aluminum shielding stripping, isolator stripping, automatic reshaping, automatic soldering and ultraviolet ray curing. Each DAC cables take the TDR & VNA measurement, guaranteeing passing the signal integrity test.
10Gtek Products Show
From GBIC to SFP, 10Gtek witnessed the development of the optical communication industry.
In the past 10 years, 10Gtek has provided a variety of communication products to users around the world.
Today, 10Gtek continues to move forward. For the coming decade, we are prepared.
*200G and 400G transceivers, DACs, AOCs are launched, contact us for details.
